How to Install a SwingClear Mailbox Mount in 3 Easy Steps

Apr 10

Installing a SwingClear mailbox mount is one of the best ways to protect your mailbox from damage caused by vehicles, snowplows, and harsh weather. Thanks to its swing-away impact-resistant design, this innovative mount helps prevent costly repairs while keeping your mailbox secure and USPS-compliant.

The good news? Installing a SwingClear mailbox mount is quick and hassle-free! With the right tools and a few simple steps, you can set up your mailbox in minutes.

Follow this step-by-step guide to ensure a proper and durable installation, and enjoy a long-lasting, worry-free mailbox setup!

Step 1: Gather Your Tools & Materials

Before you begin, ensure you have all the necessary components and tools for a smooth installation.

✅ What You’ll Need:

SwingClear Mailbox Mount Kit (includes mailbox post, swing-away arm, and mounting hardware)
Base Pipe & Spade Plate (provided in kit)
Mailbox (ensure it’s USPS-approved)
Drill & Screws (for securing the mount)
Level & Measuring Tape (to ensure proper alignment)
Adjustable Wrench (for tightening bolts)
Hammer (for driving the base into the ground)

💡 Pro Tip: If installing a new mailbox post, choose a durable material like galvanized steel to resist rotting or rust over time.

Step 2: Install the SwingClear Mount

With your tools ready, it’s time to install the SwingClear mount onto your mailbox post. This step ensures that your mailbox can pivot properly when hit, absorbing impact instead of breaking.

🔧 Follow These Steps:

1️⃣ Attach the Spade Plate to the Base Pipe

  • Secure the spade plate to the base pipe (the pipe that has a flattened end) using two hex bolts (included in the kit).
  • Loosen the chrome set bolt near the top of the base pipe.

2️⃣ Install the Base Pipe

  • Mark the installation point: First, determine where you want the front of your mailbox to be. From that point, measure 52” for a medium box or 54” for a large box toward the ditch and mark the location for your base pipe.
  • Insert the base driver into the base pipe and tilt it slightly (about 5 degrees) away from the road.
  • Using a hammer, drive the base pipe into the ground until the bottom of the spade plate is level with the ground.
  • Remove the base driver and check the tilt. If needed, adjust the tilt before proceeding.

💡 Pro Tip: If you’re installing the base pipe in dry, clay-heavy soil, installation will be easier after rain when the ground is softer.

3️⃣ Set the Upright Post

  • Slide the bent upright post into the base pipe and loosely tighten the set bolt with a wrench.
  • Adjust the bent top of the upright post so that it faces directly toward the road.

Step 3: Attach the Mailbox & Adjust the Height

Now that the mount is securely in place, it's time to attach your mailbox and ensure it meets USPS regulations.

📦 Securing Your Mailbox:

  • Use a SwingClear mounting board or a custom mounting board to attach your mailbox to the red or black boom arm using the provided carriage bolts.
  • Slide the swivel joint end of the boom arm onto the bent upright post.

📏 Adjust the Height to Meet USPS Standards:

  • Ensure the bottom of the mailbox sits 42”-46” above the road surface by loosening the set bolt at the top of the base pipe.
  • Tighten the bolt completely to prevent spinning.
  • Optional: For extra stability, insert two self-tapping screws into the top of the  base pipe to lock the upright post in place.
    Enjoy a Safer, Longer-Lasting Mailbox Post!

That’s it—you’ve successfully installed your SwingClear mailbox mount! Now, your mailbox is:

Protected from accidental damage by vehicles & snowplows
Built to withstand extreme weather conditions
USPS-compliant for reliable mail delivery
Designed to last for years with minimal maintenance

Say goodbye to frequent mailbox repairs and replacements! With SwingClear, your mailbox is secure, durable, and impact-resistant—ready to handle whatever comes its way.

👉 Order your SwingClear mailbox mount today and install it in minutes! 🚀

FAQs & Installation Tips

Q: How do I know the exact placement for my base pipe?

If you’re not using a standard medium or large mailbox, first attach your mailbox to the boom arm. Then, lay the boom arm down so that the front of the mailbox is at the desired location. The spot where the back of the boom arm touches the ground is where you should install the base pipe.

Q: What if I’m installing my mailbox in a deep ditch?

If the installation location is 6” or more below road level, you’ll need a SwingClear Upright Extension (Model 025) to ensure proper height. These are available at www.swingclear.com.

Q: What should I do if I hit a rock while installing the base pipe?

If you hit a hard object, the sound of the pipe will change when struck. Simply pull the base pipe out and reinstall it a few inches away.

🔧 Additional items that may help with installation:

  • Hammer (for driving the base pipe)
  • Tape measure (for accurate height and positioning)
  • Adjustable wrench (for tightening bolts)
